Smarter Sensors, Smarter Data

The IA Series of pollution monitors offer low-cost, ultra sensitive gas sensor for pollution detection. After two years of development, we created a Digital/Analogue sensor using AI and Hardware integration to produce a sensor capable of measuring 10 parts per billion with a response time of 60 seconds.

The sensors are combined with a powerful quad-core computing platform to provide auto-calibration allowing the sensors to match expensive chemiluminescence sensors for accuracy. All IA series sensors are simple to setup and deploy and can be linked to a local server, the Cloud, third party systems or a UTMC system allowing for networked results in real-time.

Smart Sensor

The sensor uses a powerful quad core computer and advanced AI algorithms to calculate and transmit accurate pollution readings.

Precision Results

The IA series provides detailed pollution information with real-time precision with UTMC compatability.

Products

Air Quality Sensors

XA-REF

Reference Air Quality Sensor with Dual NO2 and Class 1 Laser Particle Sensor

  • PM1, PM2.5, PM4.25, PM10

  • Two High Sensitivity Gas Sensors NO2, NO, CO, SO2, O3, H2S, CL2

  • Additional Gas Sensors can be added without a Limit

  • Gas Sampling 200 samples per second

  • Reporting 20 seconds to 20 minutes

  • Temperature, Humidity Measurement

  • Optional Air Pressure Sensor

  • AI-driven auto-calibration and forecasting

  • Maintenance-free operation for up to 5 years

  • Cloud Manager and API support City Managers

  • Supports Yunex and Swarco City Managers

IA-NO2

Nitrogen Dioxide Sensor

  • High-frequency Sampling at 200 Samples Per Second allows AI digital processing.

  • AI And Statistical Build Pollution Profile

  • Auto Calibration extends life up to 5 years

  • Real-Time Pollution for AI target

  • Resolution 10 ppb, augmented to 5 ppb

  • Range 5 ppb to 20,000 ppb, 10 μg/m3 to 38,000 19 µg/m3

XA-OPS

Optical Particle Sensor

PM1, PM2.5, PM4.25, PM10

• Reporting 20 seconds to 20 minutes

• Temperature, Humidity Measurement

• AI-driven auto-calibration and forecasting

• Maintenance-free operation for up to 5 years

• Cloud Manager and API support City Managers

• Supports Yunex and Swarco City Managers

IA-NO

Nitrous Oxide Sensor

  • Advanced electrochemical gas sensor with accurate readings from 10 ppb to 20000 ppb (19 µg/m3 to 38000 µg/m3).

  • Internal temperature sensor

  • Alerts and AI forecasts (utilising Xan AI)

  • Response time less than 40 seconds.

  • Networked Auto-Calibration (utilising Xan AI)

  • Temperature range of -30°C to 50°C

  • Humidity range of 15% - 90%

  • 3G, 4G, WiFi, Bluetooth, LoRa, ZigBee, Mesh connectivity

IA-SO2

Sulphur Dioxide Sensor

  • Advanced electrochemical gas sensor with accurate readings from 5 ppb to 10000 ppb (13 µg/m3 to 27500 µg/m3).

  • Internal temperature sensor

  • Alerts and AI forecasts.

  • Response time less than 40 seconds.

  • Networked Auto-Calibration

  • Temperature range of -30°C to 50°C

  • Humidity range of 15% - 90%

  • 3G, 4G, WiFi, Bluetooth, LoRa, ZigBee, Mesh connectivity

IA-CO

Carbon Monoxide Sensor

  • Advanced electrochemical gas sensors can detect a wide range of concentrations from 10 ppb to 1000000 ppb (12 µg/m3 to 1205000 µg/m3).

  • Internal temperature sensor

  • Alerts and AI forecasts (utilising Xan AI).

  • Response time less than 40 seconds.

  • Networked Auto-Calibration (utilising Xan AI)

  • Temperature range of -30°C to 50°C

  • Humidity range of 15% - 90%

  • 3G, 4G, WiFi, Bluetooth, LoRa, ZigBee, Mesh connectivity
